| TECHNICIAL SPECIFICATIONS |
|
RAW WATER PARAMETERS (LIMITS) |
| TFC spiral rounded membranes, 4'' |
|
Tds: 0 - 2000 ppm |
| Flow adjustment valve |
|
pH: 6-8 |
| FRP membrane housings |
|
Temperature: 10° - 30°C |
| Manometers with glycerine (2 pieces) |
|
Hydrogen Sulfur (H2S) Tolerance: 0 |
| ST 37 furnaced body |
|
Microbiological Tolerance: 0 |
| Mechanical control unit (Green when producing, yellow when the tank is full and red warning light turns on when there is a problem) |
|
Pressure: 2 - 5 bar |
| Aqua filtration system, 5 micron |
|
Silica: < 25 ppm |
| Conductivity measurement and following on the screen |
|
Max Ferro Tolerance: 0,05 ppm |
| Pure water and drain water flow meters |
|
Oil-Gress Tolerance: 0 |
| Float switch - 3 meter |
|
Turbidity: NTU < 1 |
| Dosing pump outlet |
|
Free Chlorine: < 0,2 mg IL |
| IP56 protection |
|
|
| Low pressure switch (Piccola Soft) / Low and high pressure switch (Piccola Soft Plus) |
|
|
| PPRC low and high pressure piping |
|
|
| With Rotoflow type pump (Piccola Soft) / |
|
|
| Motor delay (Piccola Soft Plus) |
|
|
| Flush (Piccola Soft Plus) |
|
|
| Motor and phase production (Piccola Soft Plus) |
|
|
